+ Technical Specifications

Operation

Metal control chain.

Dimensions

Width 610mm minimum - 3010mm maximum Drop 600mm minimum - 3010mm maximum

Spring Assist

830mm minimum width.

Roller Tube

Regular 43mm Heavy Duty 44mm Super Heavy Duty 49mm

Base Rail

Oval (15mm x 26mm) is standard. Base rail colours. Oval, D30 and D30 Silent: Natural Anodised, Pure White, Bone, Sandstone, Dune, Bronze Pearl, Black.

Idler

The idle pin extends up to 10mm in 1mm increments for improved installation.

Brackets

Composition - Press formed steel, pre treated and powder coated. Colours available are Silver Grey, Pure White, Sandstone and Black.

Chain Control

Rollease Acmeda RB09 high polish finish, comfort grip release wheel, advanced snaplock, screwless assembly, self locating installation feature. Smooth operation with increased load capacity.

Colours

Nickel Plated Steel and Black Nickel. Options are Stainless Steel chain (refer to pricing guide for surcharge) or Plastic chain in the following colours: Silver Grey, Pure White, Sandstone and Black.

+ Options

Base Rail

D30 (14mm x 31mm) D30 Silent (14mm x 31mm) Flat (11mm x 22mm) Flat Heavy Duty (41mm x 15mm) please refer to pricing guide for surcharge.

Double Brackets

Double Brackets are available in Pure White, Silver Grey, Sandstone and Black. Same Side: 122 x 122mm Opposite Side: 100 x 115mm Front Blind must be right control. Back Blind must be left control.

Slimline Double Brackets

Slimline Combo Double Brackets are available in Pure White, Silver Grey, Sandstone and Black. Measurements are 85mm x 148mm. Top Back same side control, both blinds need to be standard roll. Top Front same side control, front blind needs to be reverse roll, back blind needs to be standard roll.

Easy Link System

Allows multiple blinds (maximum of three) to be controlled by one chain. Please refer to pricing guide for charges.

When ordering easy links on double brackets, you can only order same side or slimline combo double brackets and there is an extra charge (please refer to pricing guide) for the intermediate double bracket additional to the other charges.

May not roll up even with each other.

Knuckle Joints

Knuckle Joints: Easy Link 45° Easy Link 90° Please refer to pricing guide for surcharge.

FRS Valance

There are two sizes available 100mm or 120mm. Colours: Natural Anodised, Snow White, Sandstone and Black. Not compatible with double brackets. Please refer to Roller Blind price list for pricing.

CF 90 Cassette

3 options:

• Box Only: refer to pricing guide for charge
• Side Guides Only: refer to pricing guide for charge
• CF Cassette 90 with Side Channel: please refer to pricing guide for charges.

Available in Round or Square Cassette

Colours available: Natural Anodised, Pure White, Sandstone and Black.

Wire Guide

Wire Stainless Steel

Only suitable for D30, Flat and HD Flat base rails only

Please specify recess or face Please refer to pricing guide for charges.

Bonded Pelmets

Standard Box Sizes (return x drop) (Please Specify)

A. 105mm x 140mm to suit 1 face fit roller B. 40mm x 170mm to suit 1 recess fit roller C. 160mm x 150mm to suit same side double bracket rollers D. 120mm x 190mm to suit slimline combo bracket rollers.

Bonded Pelmets are based on wing joins where required, railroading is possible and price is on application. All sizes given must be internal pelmet size. Please refer to pricing guide for charges.

Motorisation

Rollease Acmeda and Somfy.
